Overview
SDRB-P585Z uses end-of-line piping and 40 MPa output pressure in place of the SDRB-N585H loop arrangement at 31.5 MPa. Higher motor power and stronger transmission components retain the same flow and speed while allowing greater conveying distance. The model denotes 585 mL/min nominal flow, P = 40 MPa and Z = end-of-line piping.
Selection and operation
Install indoors and allow space for replenishment and servicing. Use clean grease and connect the motor for the specified direction of rotation.
Technical documentation
Specifications, installation dimensions and diagrams are provided in the following sheets and the attached PDF. Use the data for the selected model and configuration. Check the connections, operating medium and installation space before ordering.
